Product Overview
The Siemens 6ES7138-7EA01-0AA0 is a specialized SIMATIC ET 200S Terminal Module, designated TM-P15S23-A0, designed for exclusive use with PROFIsafe (fail-safe) electronic modules within the modular ET 200S distributed I/O system. This 15 mm wide terminal module features screw-type terminals and is crucial for providing secure and reliable electrical connections for safety-related signals. It ensures proper potential grouping and connection points for fail-safe digital inputs, digital outputs, or power modules, forming an integral part of safety-critical automation applications where high reliability and functional safety are paramount.
Specifications
| Article Number | 6ES7138-7EA01-0AA0 | Product Type | Terminal Module for ET 200S |
| Net Weight | 0.06 kg | Series | SIMATIC ET 200S |
| Module Type | TM-P15S23-A0 | Compatible Electronic Modules | ET 200S PROFIsafe Modules (e.g., F-DI, F-DQ, F-PM) |
| Connection Type | Screw terminals | Number of Terminals | Varies based on internal configuration, typically multiple terminals per channel for safety |
| Module Width | 15 mm | Potential Group Pitch | 20 mm |
| Wire Cross-Section (min.) | 0.25 mm² (AWG 24) | Wire Cross-Section (max.) | 1.5 mm² (AWG 16) |
| Mounting Type | Snaps onto DIN rail | Color | Light gray (typical for PROFIsafe accessories) |
| Operating Temp. | -25 °C to +60 °C | Dimensions (H x W x D) | Approx. 119.5 mm x 15 mm x 75 mm (HxWxD of terminal module only) |
| Country of Origin | Germany |
Note: For precise application and detailed technical specifications for the 6ES7138-7EA01-0AA0 SIMATIC ET 200S Terminal Module for PROFIsafe Modules (TM-P15S23-A0), please consult the relevant SIMATIC ET 200S System Manual and the specific PROFIsafe module manuals for exact wiring diagrams, terminal assignments, and safety-related installation guidelines.
Features
The Siemens 6ES7138-7EA01-0AA0 SIMATIC ET 200S Terminal Module offers key features for fail-safe wiring:
- Dedicated for PROFIsafe: Ensures proper integration with safety-critical ET 200S modules.
- Screw Connections: Provides highly reliable and vibration-resistant wire terminations.
- Compact 15 mm Design: Maintains the space-saving benefits of ET 200S.
- Potential Grouping: Facilitates clear and organized potential distribution.
- Hot-Swappable Support: Enables module replacement without disrupting field wiring (with compatible electronic modules).
- Robust Construction: Built for industrial durability and long-term reliability.
- Clear Identification: Often includes coding and labeling areas for ease of installation and maintenance.
Applications
The Siemens 6ES7138-7EA01-0AA0 SIMATIC ET 200S Terminal Module for PROFIsafe Modules is essential in applications requiring functional safety and robust I/O connections:
- Machine Safety: Used in emergency stop circuits, light curtains, two-hand controls, and safety gates.
- Process Industry: For fail-safe monitoring and control in chemical plants, oil & gas facilities, and power generation.
- Robotics: Ensuring safe operation of robotic cells and safeguarding personnel.
- Material Handling Systems: Implementing safety functions in conveyors, automated guided vehicles (AGVs), and lifting equipment.
- Packaging Machinery: Safeguarding operators and processes in high-speed packaging lines.
- Presses and Forming Machines: Ensuring safe operation and preventing unintended movements.
- Any Application with Functional Safety: Where compliance with safety standards (e.g., IEC 61508, ISO 13849) is required.
