Panoramica del prodotto
High-Precision Diagnostic Control
IL Siemens 6ES7322-8BH01-0AB0 is a 16-channel “High Feature” transistor output module designed for automated systems requiring granular error monitoring. It features individual channel diagnostics for wire-break and short-circuit detection, alongside a programmable “Substitute Value” function that ensures actuators transition to a safe state (Hold, 0, or 1) during a CPU stop or communication failure.
Expert Sourcing & Technical Assurance
As a specialized global supplier, GoldRayline addresses the pain point of sourcing rare and high-feature S7-300 components. We maintain a massive inventory of original Siemens parts at highly competitive pricing, ensuring immediate dispatch for urgent maintenance. Every Codice articolo: 6ES7322-8BH01-0AB0 undergoes rigorous diagnostic verification on original Siemens test racks before shipping, providing 100% functional certainty for your critical infrastructure.
Specifiche
| Numero di modello | Codice articolo: 6ES7322-8BH01-0AB0 | Marchio del prodotto | SIEMENS |
| Tipo di prodotto | Modulo di uscita digitale | Serie di prodotti | SIMATIC S7-300 |
| Numero di uscite | 16 (High Feature) | Corrente di uscita | 0.5 A per Channel |
| Tipo di output | Transistor (P-Switching) | Tensione nominale | 24 V CC |
| Diagnostica | Wire-break / Short-circuit | Valore sostitutivo | Programmable per Channel |
| Isolamento | 75V DC (Groups/Bus) | Lamp Load | Max. 5 W |
| Switching Freq. | 100 Hz (Inductive) | Address Space | 2 Byte (Output) |
| Assorbimento di corrente | typ. 70 mA (Backplane) | Perdita di potenza | typ. 5 W |
| Dimensioni (L x A x P) | 40 × 125 × 117 mm | Classe di protezione | IP20 |
| Temperatura di esercizio | da 0 °C a +60 °C | Product Net Weight | approx. 0.23 kg |
Related Siemens SIMATIC S7-300 Digital Output Modules
GoldRayline offers a specialized selection of diagnostic and high-density output modules. These models from our 3,911-item database are selected to match your specific S7-300 channel requirements and field-side switching technology.
| Numero di modello | Output Count | Tipo di output | Caratteristica speciale | Connessione |
| Codice articolo: 6ES7322-8BH10-0AB0 | 16 Outputs | Transistor | M-Switching Diag. | 40 pin |
| 6ES7321-7TH00-0AB0 | 16 Inputs | 24 V CC | Diagnostic Input | 20 pin |
| 6ES7322-1BL00-0AA0 | 32 Outputs | Transistor | High Density 0.5A | 40 pin |
| 6ES7322-5HF00-0AB0 | 8 Outputs | Staffetta | High Power 5A | 40 pin |
| 6ES7322-5FF00-0AB0 | 8 Outputs | AC (Triac) | 2A High Feature | 40 pin |
| 6ES7322-1HH01-0AA0 | 16 Outputs | Staffetta | 2A Standard | 20 pin |
| 6ES7392-1AM00-0AA0 | N / A | Accessorio | Connettore frontale | 40 pin |
