High-Frequency Pulse Processing
Der Siemens 6ES7350-1AH03-0AE0 is a single-channel function module (FM) designed for SIMATIC S7-300 racks. It processes high-speed pulse signals up to 500 kHz from incremental encoders, proximity switches, or flow meters. By handling counting tasks independently of the CPU, this module ensures accurate position detection and frequency measurement even in applications with rapid signal changes. It supports various counting modes, including continuous, single, and periodic counting, and features integrated digital outputs for direct response to reaching comparator values.
B2B Supply & Inventory Management
GoldRayline serves as a direct procurement channel for original S7-300 hardware. We address the market demand for specialized function modules by maintaining a stable inventory of the FM 350-1. Our business model focuses on price competitiveness and logistical speed. By leveraging an established global supply chain, we provide original Siemens components without the lead times typically associated with factory orders. We operate a customer-centric delivery system aimed at supporting the long-term maintenance needs of industrial traders and engineers.
Technische Daten
| Modellnummer | 6ES7350-1AH03-0AE0 | Produktmarke | SIEMENS |
| Produkttyp | Counter Module (FM 350-1) | Produktserie | SIMATIC S7-300 |
| Anzahl der Kanäle | 1 Channel | Zählfrequenz | Max. 500 kHz |
| Eingabetyp | 5V / 24V Incremental | Encoder-Unterstützung | RS422 / 24V signals |
| Digitale Eingänge | 1 (Gate/Latching) | Digitale Ausgänge | 2 (Comparator) |
| Isolierung | Tested at 500V DC | Counting Range | 32 Bits (±2^31-1) |
| Current Draw (5V) | max. 160 mA (Backplane) | Stromausfall | typ. 4.5 W |
| Abmessungen (B x H x T) | 40 × 125 × 120 mm | Schutzklasse | IP20 |
| Betriebstemperatur. | 0 °C bis +60 °C | Product Net Weight | approx. 235 g |
