نظرة عامة على المنتج
Elite Processing for Data-Intensive Automation
ال 6ES7416-3ES07-0AB0 sits at the pinnacle of the S7-400 standard CPU range, engineered specifically for high-end applications that demand extreme memory capacity and communication versatility. Boasting a massive 16 MB work memory (split into 8 MB for code and 8 MB for data), this processor is designed to manage entire factory sections, complex chemical refineries, or massive power distribution grids. Its V7.0 architecture delivers a lightning-fast bit-processing speed of 12.5 ns, allowing it to execute sophisticated mathematical algorithms and high-speed motion control without affecting the overall system scan time.
Next-Generation Connectivity and System Longevity
GoldRayline recognizes that the 3ES07 revision is the modern benchmark for S7-400 infrastructure. By integrating a PROFINET interface with a 2-port switch directly alongside MPI/DP and PROFIBUS DP ports, this CPU eliminates the need for multiple communication processors. We focus on providing this latest V7.0 hardware to ensure our B2B partners receive the longest possible support lifecycle. Whether you are performing a technological refresh or replacing a failed unit in a high-priority line, our verified stock of the CPU 416-3 PN/DP ensures your system remains at the cutting edge of industrial reliability.
تحديد
| رقم الموديل | 6ES7416-3ES07-0AB0 | ماركة | SIEMENS |
| فئة المنتج | Central Processing Unit | إصدار البرنامج الثابت | V 7.0 |
| Work Memory (Total) | 16 MB (8MB/8MB) | Bit Logic Speed | 12.5 ns |
| Integrated Interface 1 | PROFINET (2-Port RJ45) | Integrated Interface 2 | MPI/DP (RS485) |
| Integrated Interface 3 | بروفيبوس دي بي | I/O Address Space | 16 KB Total |
| Slot Width | 50 mm (2 Slots) | السحب الحالي | max. 1.3 A (5V DC) |
| Max PROFINET Devices | 256 | Multi-computing | Up to 4 CPUs |
| أبعاد | 50 x 290 x 219 mm | الوزن الصافي | approx. 900 g |
Specialized S7-400 Hardware & Interfacing
ال 6ES7416-3ES07-0AB0 is a dual-slot module that serves as a communication hub. GoldRayline provides the specific memory and power components required to sustain its high-speed data throughput.
| رقم الموديل | نوع الوحدة | Technical Role | اتصال |
| 6ES7952-1AP00-0AA0 | Flash Memory Card | 8 MB Non-Volatile Storage | MC 952 Slot |
| 6ES7952-1AY00-0AA0 | Flash Memory Card | 64 MB Extended Storage | MC 952 Slot |
| 6ES7407-0RA02-0AA0 | مزود الطاقة | PS 407 20A (High Capacity) | 120/230V AC/DC |
| 6ES7400-1JA01-0AA0 | UR1 Rack | 18-Slot Main Chassis | Integrated Backplane |
| 6ES7155-6AU01-0BN0 | ET 200SP IM | PROFINET Fieldbus Link | RJ45 BusAdapter |
| 6ES7971-0BA00-0AA0 | بطارية ليثيوم | 3.6V Backup Cell | PS Battery Slot |
| 6ES7492-1AL00-0AA0 | الموصل الأمامي | 48-Pin Wiring Connector | I/O Module Link |
