نظرة عامة على المنتج
Superior Memory Capacity for Complex Process Control
ال 6ES7414-2XK05-0AB0 is a high-tier mid-range controller within the SIMATIC S7-400 family, specifically distinguished by its expanded 1 MB work memory (512 KB for code and 512 KB for data). This version (V5.0) is engineered to handle significantly larger program structures and more complex data blocks than its predecessors. With a bit-processing time reduced to just 45 ns, it provides the near-instantaneous response required for precision motion control, high-frequency signal processing, and extensive PID regulation in sectors like pharmaceutical manufacturing and water treatment.
Original V5.0 Hardware for Precise Replacements
GoldRayline specializes in sourcing the exact 05-0AB0 revision to ensure that our B2B partners can perform “like-for-like” hardware swaps without the need for firmware downgrades or costly software re-validation. We understand that in regulated industries, changing a CPU revision can trigger a chain of compliance hurdles. By maintaining a dedicated stock of this V5.0 processor, we provide a direct path to system restoration, ensuring your existing S7-400 rack remains operational with the exact performance characteristics your process requires.
تحديد
| رقم الموديل | 6ES7414-2XK05-0AB0 | ماركة | SIEMENS |
| فئة المنتج | Central Processing Unit | إصدار البرنامج الثابت | V 5.0 |
| Total Work Memory | 1 MB (512KB/512KB) | Bit Logic Speed | 45 ns |
| واجهة MPI/DP | 12 Mbit/s (Max) | PROFIBUS DP Port | Dedicated RS485 |
| I/O Address Space | 8 KB Total | استهلاك الطاقة | 1.1 A at 5V DC |
| الاحتفاظ بالبيانات | Via Backup Battery | Multi-computing | Up to 4 CPUs |
| أبعاد | 25 x 290 x 219 mm | الوزن الصافي | approx. 700 g |
Related S7-400 System Components
ال 6ES7414-2XK05-0AB0 requires specific memory cards and interface cables that match its V5.0 performance tier. GoldRayline offers these as verified companions to your CPU purchase.
| رقم الموديل | نوع الوحدة | Technical Role | اتصال |
| 6ES7952-1KK00-0AA0 | RAM Card | 1 MB Work Memory Extension | MC 952 Slot |
| 6ES7952-1AP00-0AA0 | Flash Card | 8 MB Bulk Program Storage | MC 952 Slot |
| 6ES7407-0DA02-0AA0 | مزود الطاقة | PS 407 4A (Standard Load) | 120/230 فولت تيار متردد |
| 6ES7443-1EX20-0XE0 | Ethernet CP | CP 443-1 for V5.0 CPUs | RJ45 PROFINET |
| 6ES7901-0BF00-0AA0 | MPI Cable | RS485 Programming Link | موصل فرعي D ذو 9 دبابيس |
| 6ES7971-0BA00-0AA0 | بطارية ليثيوم | 3.6V AA Cell for PS | Battery Tray |
| 6ES7492-1AL00-0AA0 | الموصل الأمامي | 48-Pin Wiring Connector | I/O Module Link |
